压力振荡管内波动行为的可视化实验研究

郭江涛 周一卉 胡大鹏 刘志军 黄兆锋 高凤

郭江涛, 周一卉, 胡大鹏, 等. 压力振荡管内波动行为的可视化实验研究[J]. 实验流体力学, doi: 10.11729/syltlx20220039
引用本文: 郭江涛, 周一卉, 胡大鹏, 等. 压力振荡管内波动行为的可视化实验研究[J]. 实验流体力学, doi: 10.11729/syltlx20220039
GUO J T, ZHOU Y H, HU D P, et al. Visualization experiment of wave dynamics in pressure oscillation tube[J]. Journal of Experiments in Fluid Mechanics, doi: 10.11729/syltlx20220039
Citation: GUO J T, ZHOU Y H, HU D P, et al. Visualization experiment of wave dynamics in pressure oscillation tube[J]. Journal of Experiments in Fluid Mechanics, doi: 10.11729/syltlx20220039

压力振荡管内波动行为的可视化实验研究

doi: 10.11729/syltlx20220039
基金项目: “变革性技术关键科学问题”国家重点研发计划(气波膨胀制冷新原理与关键技术,2018YFA0704600)
详细信息
    作者简介:

    郭江涛:(1997—),男,山西忻州人,硕士研究生。研究方向:振荡管内气波流动测试技术,高速纹影技术。通信地址:辽宁省大连市甘井子区凌工路2号大连理工大学西部校区化工学院H102实验室(116024)。E-mail:Gjt@mail.dlut.edu.cn

    通讯作者:

    E-mail:zflower@dlut.edu.cn

  • 中图分类号: TQ051

Visualization experiment of wave dynamics in pressure oscillation tube

  • 摘要: 气波制冷机具有制冷效率高、可带液工作等优点。为深入研究气波制冷机核心部件压力振荡管内部波系运动,设计了一套双开口压力振荡管可视化流场测量平台,利用视场拼接和纹影技术获得气波振荡管内密度梯度场的定量表达,并与二维欧拉方程理论计算结果进行了交叉对比验证,误差为3.2%,证明基于纹影技术追踪管内复杂波系运动的方法不仅直观可视且准确可靠。基于上述方法,对不同压比和转速下的气波振荡管内波系开展了深入实验研究。实验结果表明,增加压比或转速均会提升激波马赫数。压比由1.5增至3.0时,激波强度与膨胀波强度均显著增加,强化了对管口的膨胀过程。转速由800 r/min提升至2400 r/min时,膨胀波波系运动路径逐渐向管口方向弯曲,减缓了膨胀波在管口运动的速度,增加了膨胀波对管口的作用时间。
  • 图  1  波转子波图

    Figure  1.  Wave chart of rotor

    图  2  实验流程图

    Figure  2.  Experimental process diagram

    图  3  实验平台实物图

    Figure  3.  Experimental platform test rig

    图  4  密度梯度计算流程

    Figure  4.  Density gradient calculation process

    图  5  压力振荡管全局波图(α = 2,n = 1400 r/min)

    Figure  5.  Global wave diagram of pressure oscillation tube(α = 2, n = 1400 r/min)

    图  6  纹影灰度波图(α = 1.5,n = 800 r/min)

    Figure  6.  Schlieren gray wave diagram (α = 1.5, n = 800 r/min)

    图  7  密度梯度波图(α = 1.5,n = 800 r/min)

    Figure  7.  Density gradient wave diagram (α = 1.5, n = 800 r/min)

    图  8  压力振荡管压力曲线(α = 2)

    Figure  8.  Pressure curve of pressure oscillation tube (α = 2)

    图  9  密度梯度波图对比图(α = 2,n = 1400 r/min)

    Figure  9.  Contrast diagram of density gradient wave diagram (α = 2, n = 1400 r/min)

    图  10  中心轴线密度梯度对照曲线(x = 500 mm)

    Figure  10.  Central axis density gradient comparison curve (x = 500 mm)

    图  11  压力对照曲线(α = 2,n = 1400 r/min)

    Figure  11.  Pressure comparison curve (α = 2, n = 1400 r/min)

    图  12  各参量与压比的关系

    Figure  12.  Relationship between parameters and pressure ratio

    图  13  固定转速,不同压比下波图(n = 800 r/min)

    Figure  13.  Wave diagram under different pressure ratios(n = 800 r/min)

    图  14  各参量与转速的关系

    Figure  14.  Relationship between parameters and speed

    图  15  固定压比,不同转速下波图(α = 2.5)

    Figure  15.  Wave diagram under different speed (α = 2.5)

    图  16  激波形成位置至管口的距离与压比的关系曲线

    Figure  16.  Curve of shock wave maximum position and pressure ratio

    表  1  实验参数

    Table  1.   Experimental parameters

    参数名称参数值参数名称参数值
    管道长度600 mm可视段长度450 mm
    管道截面12 × 12 mm2喷嘴截面32 × 15 mm2
    喷嘴压力150~300 kPa (绝压)最大压力110 kPa (绝压)
    电机转速800~2400 r/min最大流量0.4 kg/s
    下载: 导出CSV
  • [1] COTTERLAZ-RENNAZ M. Wellhead gas refrigerator field strips condensate[J]. World Oil, 1971, 173(6): 60–61.
    [2] 刘伟, 胡大鹏. 气波制冷技术研究现状[J]. 制冷, 2002, 21(4): 19–24. doi: 10.3969/j.issn.1005-9180.2002.04.005

    LIU W, HU D P. The research situation of gas wave refrigeration technology[J]. Refrigeration, 2002, 21(4): 19–24. doi: 10.3969/j.issn.1005-9180.2002.04.005
    [3] HANSON R K, DAVIDSON D F. Recent advances in laser absorption and shock tube methods for studies of combustion chemistry[J]. Progress in Energy and Combustion Science, 2014, 44: 103–114. doi: 10.1016/j.pecs.2014.05.001
    [4] LIU P Q, WU K H, XU S Y, et al. Influence of non-equilibrium condensation on key parameter of gas wave refrigerator[C] //Proceedings of the 7th International Conference on Informatics, Environment, Energy and Applications. 2018. doi: 10.1145/3208854.3208894
    [5] HU D P, LI R F, LIU P Q, et al. The design and influence of port arrangement on an improved wave rotor refrigerator performance[J]. Applied Thermal Engineering, 2016, 107: 207–217. doi: 10.1016/j.applthermaleng.2016.06.168[LinkOut
    [6] HU D P, YU Y, LIU P Q. Enhancement of refrigeration performance by energy transfer of shock wave[J]. Applied Thermal Engineering, 2018, 130: 309–318. doi: 10.1016/j.applthermaleng.2017.11.040
    [7] LIU P Q, LI X, LIU X Y, et al. Investigation of the shock wave formation and intensity in wave rotor[J]. Journal of Energy Resources Technology, 2021, 143(11): 111301. doi: 10.1115/1.4049585
    [8] OKAMOTO K, ARAKI M. Shock wave observation in narrow tubes for a parametric study on micro wave rotor design[J]. Journal of Thermal Science, 2008, 17(2): 134–140. doi: 10.1007/s11630-008-0134-6
    [9] OKAMOTO K, NAGASHIMA T. Visualization of wave rotor inner flow dynamics[J]. Journal of Propulsion and Power, 2007, 23(2): 292–300. doi: 10.2514/1.18439
    [10] KUREC K, PIECHNA J, GUMOWSKI K. Investigations on unsteady flow within a stationary passage of a pressure wave exchanger, by means of PIV measurements and CFD calculations[J]. Applied Thermal Engineering, 2017, 112: 610–620. doi: 10.1016/j.applthermaleng.2016.10.142
    [11] OZAWA H. Visualization of unsteady boundary-layer transition on shock-tube wall using highly sensitive fast-response TSP[C]//Proc of the 20th AIAA International Space Planes and Hypersonic Systems and Technologies Conference. 2015: 3658. doi: 10.2514/6.2015-3658
    [12] 谢爱民, 部绍清, 罗锦阳. 基于光源拼接的大视场聚焦纹影技术初步研究[J]. 实验流体力学, 2018, 32(6): 68–73. doi: 10.11729/syltlx20180012

    XIE A M, BU S Q, LUO J Y. Primary study of large-field focusing schlieren technique based on tiled light sources[J]. Journal of Experiments in Fluid Mechanics, 2018, 32(6): 68–73. doi: 10.11729/syltlx20180012
    [13] CHAN S N, LIU H X, XING F, et al. Wave rotor design method with three steps including experimental validation[J]. Journal of Engineering for Gas Turbines and Power, 2018, 140(11): 111201. doi: 10.1115/1.4038815
    [14] 郑敏, 张涵信. 无波动、无自由参数的耗散差分格式(NND)在喷流计算中的应用[J]. 空气动力学学报, 1989, 7(3): 273–281.

    ZHENG M, ZHANG H X. Application of non-oscillatory and non-free-parameters disslpative finit difference scheme to the calculation of free-jet flows[J]. Acta Aerodynamica Sinica, 1989, 7(3): 273–281.
    [15] HARGATHER M J, SETTLES G S. A comparison of three quantitative schlieren techniques[J]. Optics and Lasers in Engineering, 2012, 50(1): 8–17. doi: 10.1016/j.optlaseng.2011.05.012
    [16] SKOTAK M, ALAY E, CHANDRA N. On the accurate determination of shock wave time-pressure profile in the experimental models of blast-induced neurotrauma[J]. Frontiers in Neurology, 2018, 9: 52. doi: 10.3389/fneur.2018.00052
    [17] 张连玉. 爆炸气体动力学基础[M]. 北京: 北京工业学院出版社, 1987.
    [18] 于洋. 激波传递能量强化双开口振荡管制冷性能研究[D]. 大连: 大连理工大学, 2018.

    YU Y. Enhancement of refrigeration performance by shock-wave transmission energy in double-opening oscillating tube[D]. Dalian: Dalian University of Technology, 2018.
